SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNR

NEW LIGHT OPTICS TECHNOLOGY LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNR

  • 1
  • 2

Brand Name : New light

Model Number : 002

Certification : CPR

Place of Origin : shenzhen

MOQ : 10 pieces

Price : USD

Supply Ability : 100000 pieces per day

Packaging Details : Normal package

Material : PVC / LSZH / OFNR

Connector type : LC /UPC ; SC/UPC

Fiber type : singlemode / multi mode

Cable diameter : 0.9/2.0/3.0

cable length : 1/1.5/2/3/5/10m ( can be customized into any length as your request )

connector mode type : UPC/APC/PC

warranty : 3 Years

Cable color : Yellow / orange/white/back/aqua

Contact Now

China Factory manufacture SC/UPC-LC/UPC SM Duplex Fiber Optic Patch Cables

Product Description

SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNR

Fiber optic patch cables are used in two major application areas: computer work station to outlet and patch panels or optical cross connect distribution center.

The Fiber Optic Patch Cord series comes with a comprehensive collection of lengths and connectors to fulfill your demand for the deper line.


Key Features

· Low insertion loss and back reflection loss

· Good exchangeability

· Good Durability

· High temperature stability

· Compliant to IEC, TIA/EIA, NTT and JIS specifications

Patch cord information

1. Connector type : SC / LC / ST / FC/ MPO /MU / MTRJ / SMA

2. Fiber Type : Φ 0.9/1.8 /2.0/3.0mm ,

Fiber type : Single mode G652D(G657A1/G657A2 )

Multi-mode 62.5/125 OM1

50/125 OM2 / OM3-150 / OM3-300 / OM4

Coating Material: PVC / LSZH

3. Length: can be any length as your requirements

4. Cable color : 2.0/3.0 mm : yellow / orange / aqua / purple

0.9mm : blue / green / brown / grey / white / red / black / pink / yellow / purple / pink / aqua

SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNR

5. Core type : simplex / duplex / 4 cores / 6 cores / 8 cores / 12cores / 24cores

Parameter Unit FC, SC, LC, Armoured ST, MU MT-RJ, MPO
SM MM SM MM SM MM
PC UPC APC PC PC UPC PC PC UPC PC
Insertion loss(typical) dB ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.3 ≤0.2 ≤0.2
Return loss dB ≥45 ≥50 ≥60 ≥30 ≥45 ≥50 ≥30 ≥45 ≥50 ≥35
Operating wavelength nm 1310, 1550 1310, 1550 1310, 1550
Exchangeability dB ≤0.2 ≤0.2 ≤0.2
Vibration dB ≤0.2 ≤0.2 ≤0.2
Operating temperature °C -40~75 -40~75 -40~75
Storage temperature °C -45~85 -45~85 -45~85
Cable diameter mm Φ3.0, Φ2.0, Φ0.9 Φ3.0, Φ2.0, Φ0.9 Φ3.0, Φ2.0, Φ0.9

Applications

SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNR1. CATV

2. Active device termination

3. Telecommunication networks

4. Metro

5. Local Area Networks (LANs)

6. Data processing networks

7. Test equipment

8. Premise installation

9. Wide Area Networks(WANs)

Company Information

New light Optics Technology Limited is specialized in the development and manufacture of fiber optic products.Our company was founded in 2011 and has 6 years of manufacture experience.

Our main products are MTP/MPO,Patch Cord/Pigtails,Fiber Optical adapter, attenuator, PLC splitter ,WDM,1U Box... Etc. Our products widely used in Telecommunication Equipment ,Fiber Optical CATV, FTTH,Optical Distribution Network,Date Center Switches,etc..

Our products are exporting to USA,Europe,Brazil,Middle East,and Asia more than 60 countries and areas. We receive good reputation and lots of client from all around the world due to our high quality and good service .New light Optics Technology Limited is looking forward to cooperate with you !

Quality control

SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNRWe have a group of professional team technicians to ensure the stability of each batch of products, quality is the survival of our enterprises.

SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNR

SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNR

We will check all the goods before delivery it . ensure the quality are 100% past .

Packaging & Shipping

SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNR

1. PE packing with carton.
2. Paper packing with carton
3. According to customer's request.

SC / UPC - LC / UPC SM Simplex Optical Fiber Patch Cord Yellow PVC / LSZH / OFNR

1. T/T/ , PAYPAL , WESTEN UNION , MONEY GRAM , L/C .

2. 30% deposit in advance , 70% balance paid before delivery .
